10x Genomics Xenium Analyzer
This 10x Genomics Xenium has been fully cleaned, decontaminated, tested, inspected and verified to be in great working condition.
Year: 2023
Condition: Used
Includes:
- 10X Genomics Xenium Analyzer
- Xenium Analysis Computer
- Ametek CleanBench Vibration Isolation Table with Silent Air Compressor
- Xenium Instrument Accessory Kit
- Power and Connection Cables
- Universal Power Supply
Product Description
The 10x Genomics Xenium Analyzer is an advanced spatial biology platform designed for high-resolution, single-cell and subcellular analysis of gene expression directly within intact tissue samples. Utilizing innovative in situ hybridization chemistry, automated fluorescence imaging, and sophisticated onboard data analysis, the Xenium Analyzer enables researchers to investigate cellular organization, gene expression patterns, and tissue architecture while preserving spatial context.
The Xenium Analyzer integrates automated reagent handling, high-resolution optical imaging, transcript detection, and computational analysis into a streamlined workflow. Its high-precision imaging technology enables the detection and localization of individual RNA transcripts within tissue sections, providing detailed insights into cellular interactions, tissue microenvironments, and biological processes.
Designed for advanced research applications, the Xenium platform supports multiplexed gene expression analysis using predesigned and custom gene panels. The system provides researchers with comprehensive spatial information, making it particularly valuable for oncology, neuroscience, immunology, developmental biology, and translational research.
The Xenium Analyzer features an intuitive touchscreen interface, automated sample processing, integrated quality control, and onboard computational analysis to simplify complex spatial transcriptomics workflows.
Its advanced optical system delivers exceptional spatial resolution, enabling precise localization of RNA transcripts and detailed characterization of gene expression at the single-cell and subcellular levels.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | 10x Genomics |
| Model | Xenium Analyzer |
| Part Number | 1000481 |
| Year | 2023 |
| Instrument Type | Spatial Transcriptomics Analyzer |
| Technology | In Situ Gene Expression Analysis |
| Detection Method | Fluorescence Imaging |
| Primary Application | Spatial RNA Transcript Detection |
| Analysis Resolution | Single-cell and subcellular |
| Transcript XY Localization Precision | <30 nm |
| Transcript Z Localization Precision | <150 nm |
| Imaging Pixel Size | Approximately 0.2 µm/pixel |
| Sample Capacity | 2 slides per run |
| Maximum Tissue Analysis Area | Approximately 472 mm² per run |
| Gene Detection Capacity | Up to 5,000 genes with compatible assays |
| Gene Panel Options | Predesigned and custom panels |
| Sample Preparation | Approximately 2–3 days |
| Sample Preparation Hands-On Time | Approximately 4–6 hours |
| Sample Types | Compatible prepared tissue sections, including FFPE and fresh-frozen workflows |
| Automated Reagent Handling | Yes |
| Integrated Imaging | Yes |
| Onboard Data Processing | Yes |
| User Interface | Integrated touchscreen |
| Software | Xenium Onboard Analysis |
| Cloud Connectivity | Compatible with 10x Genomics Cloud instrument management |
| Data Export | CSV, Parquet, HDF5, MEX, Zarr, OME-TIFF |
| Instrument Width | 52.5 in (133.3 cm) |
| Instrument Depth | 27 in (68.5 cm) |
| Instrument Height | 31 in (78.7 cm) |
|
Height with Door Open |
59 in (149.8 cm) |
